Description
Upgrade your fluid control setup with the 1/4" Hose Barb Series 326 3-Way PVC Ball Valve with FKM Seals and Mounting Bracket. Designed for versatility and reliability, this valve allows you to easily divert, select, or shut off flow between multiple lines, making it an excellent choice for soft washing systems, chemical transfer applications, agricultural sprayers, and industrial fluid management.
The durable PVC body offers excellent chemical resistance, while the premium FKM seals provide dependable performance with a wide range of chemicals and cleaning solutions. Its integrated mounting bracket makes installation cleaner and more secure, allowing the valve to be firmly mounted to equipment, skids, trailers, or control panels for a more professional setup.
The Series 326 design features a common bottom port and can function as either a diverter valve or a selecting valve depending on your application. The flag handle rotates 180° and always points toward the open port for quick visual confirmation of flow direction. Positioning the handle 90° between ports shuts off flow completely to both outlet ports.
Features
- Durable PVC construction with excellent chemical resistance
- FKM seals for compatibility with many cleaning and industrial chemicals
- Integrated mounting bracket for secure installation
- 3-way valve design for diverting or selecting fluid flow
- 180° rotating flag handle indicates active flow path
- Common bottom port configuration
- Quick and secure 1/4" hose barb connections
- Ideal for soft wash, agricultural, industrial, and chemical handling applications
Specifications
- Connection Size: 1/4" Hose Barb x 1/4" Hose Barb x 1/4" Hose Barb
- Seal Material: FKM
- Maximum Pressure: 125 PSI
- Maximum Temperature: 140°F
- Through Hole Diameter: 0.312"
- Dimensions: 3.17" L x 2.90" H
- Vacuum Rated: No
